Model	V-max (Vdc)	I-max (A)	I-hold (A)	I-trip (A)	Agency Approval	Spec
SMD1210-005	30	100	0.05	0.15	RoHS
SMD1210-010	30	100	0.10	0.30	RoHS
SMD1210-020	30	100	0.20	0.40	RoHS
SMD1210-035	6	100	0.35	0.75	UL/RoHS
SMD1210-050	13.2	100	0.50	1.00	UL/RoHS
SMD1210-075	6	100	0.75	1.50	UL/RoHS
SMD1210-110	6	100	1.10	2.20	UL/RoHS
SMD1210-150	6	100	1.50	3.00	UL/RoHS

Ihold = Hold Current:maximum current device will sustain for 4 hours without tripping in 25°C still air.

ItRip = Trip Current:minimum current at which the device will trip in 25°C still air.

V-max = Maximum voltage device can withstand without damage at rated current(I-max).

I-max = Maximum fault current device can withstand without damage at rated voltage(V-max).
