Model	V-max (Vdc)	I-max (A)	I-hold (A)	I-trip (A)	Agency Approval	Spec
VLD170SS	16	100	1.70	3.40	UL/TUV/RoHS
VLD170XS	16	100	1.70	3.40	UL/TUV/RoHS
VLD175L	16	100	1.75	3.60	UL/TUV/RoHS
VLD175DII	16	100	1.75	3.60	UL/TUV/RoHS
VLD210S	16	100	2.10	4.70	UL/TUV/RoHS

Ihold = Hold Current:maximum current device will sustain for 4 hours without tripping in 25°C still air.

ItRip = Trip Current:minimum current at which the device will trip in 25°C still air.

V-max = Maximum voltage device can withstand without damage at rated current(I-max).

I-max = Maximum fault current device can withstand without damage at rated voltage(V-max).
