Model	V-max (Vdc)	I-max (A)	I-hold (A)	I-trip (A)	Agency Approval	Spec
SMD0603-010	15	40	0.10	0.30	RoHS
SMD0603-020	9	40	0.20	0.50	UL/RoHS
SMD0603-025	9	40	0.25	0.55	UL/RoHS
SMD0603-035	6	40	0.35	0.75	UL/RoHS
SMD0603-050	6	40	0.50	1.00	UL/RoHS
SMD0603-075	6	40	0.75	1.40	UL/RoHS
SMD0603-100	6	40	1.00	2.00	RoHS
SMD0603-005	15	40	0.05	0.20	RoHS
SMD0603-110	6	40	1.10	2.20	RoHS

Ihold = Hold Current:maximum current device will sustain for 4 hours without tripping in 25°C still air.

ItRip = Trip Current:minimum current at which the device will trip in 25°C still air.

V-max = Maximum voltage device can withstand without damage at rated current(I-max).

I-max = Maximum fault current device can withstand without damage at rated voltage(V-max).
