Model	V-max (Vdc)	I-max (A)	I-hold (A)	I-trip (A)	Agency Approval	Spec
SMD0805-010	15	100	0.10	0.30	RoHS
SMD0805-020	9	100	0.20	0.50	UL/RoHS
SMD0805-035	6	100	0.35	0.75	UL/RoHS
SMD0805-050	6	100	0.50	1.00	UL/RoHS
SMD0805-075	6	40	0.75	1.50	UL/RoHS
SMD0805-100	6	100	1.00	1.95	UL/TUV/RoHS
SMD0805-110	6	100	1.10	2.20	UL/RoHS
SMD0805-005	15	100	0.05	0.20	RoHS
SMD0805-025	9	100	0.25	0.55	RoHS

Ihold = Hold Current:maximum current device will sustain for 4 hours without tripping in 25°C still air.

ItRip = Trip Current:minimum current at which the device will trip in 25°C still air.

V-max = Maximum voltage device can withstand without damage at rated current(I-max).

I-max = Maximum fault current device can withstand without damage at rated voltage(V-max).
